| SK-ECW16A | SK-ECW16A |
| Charging Mode | Mode 3 IEC 62196-2 By TUV |
| Rated Voltage | 250V(1Phase) AC / 480V(3Phase) AC |
| Rated Current | MAX. 16A |
| Insulation Resistance | >1000MΩ,DC500V |
| Contact Impedance | 0.5MΩ Max |
| Withstand Voltage | 2000V |
| Mechanical Life | Unloaded Plugged>10000 |
| Waterproof Grade | IP54(mating) |
| Plastic Shell | Thermoplastic Plastic |
| Conductor | Copper alloy,Silver plated surface |
| Working Environment Temperature | -20℃-60℃ |
| Terminal Temperature Rise True | <50K |
| Insertion and Extraction Force | <100N |
| Cable Length | 5M or customized |
| Product Parameter | SK-ECW32A |
| Charging Mode | Mode 3 IEC 62196-2 By TUV |
| Rated Voltage | 250V(1Phase) AC / 480V(3Phase) AC |
| Rated Current | MAX. 32A |
| Insulation Resistance | >1000MΩ,DC500V |
| Contact Impedance | 0.5MΩ Max |
| Withstand Voltage | 2000V |
| Mechanical Life | Unloaded Plugged>10000 |
| Waterproof Grade | IP54(mating) |
| Plastic Shell | Thermoplastic Plastic |
| Conductor | Copper alloy,Silver plated surface |
| Working Environment Temperature | -20℃-60℃ |
| Terminal Temperature Rise True | <50K |
| Insertion and Extraction Force | <100N |
| Cable Length | 5M or customized |
