Applicable to USA/China/EU standard,adjustable to 16A/32A/40A charging current with single phase or three phase.LED smart touch screen,multi-touch setting is more convenient.Built-in lightning protection/overvoltage/over-temperature/overcharge/leakage protection。It can be monitor the charging status by APP, Bluetooth,4G, and support RFID cards。
| Product parameters | SK-EV40 |
| Input Voltage | 85V-480V |
| Input Frequency | 50-60Hz |
| Output Voltage | 85V-480V |
| Current | 16A/32A/40A Adjustable |
| Max. Output Power | 22KW |
| Charging Mode | Mode 3 in accordance with IEC 61851 |
| LCD | 3.5 Inch Touch Display |
| Smart Power Adjustment | Yes |
| APP | Yes |
| Network Interface | Ethernet/4G/WIFI optional |
| Access Control | RFID Available |
| Working Temperature | -20℃-60℃ |
